| U-Factor | 0.22 - 0.30 (NFRC 100) |
|---|---|
| SHGC | 0.21 (Low-E) |
| Air Infiltration | 0.05 cfm/ft² (ASTM E283)✓ ASTM E283/E283M-2019 Certified (Certificate ID: 221010012SHF-001) |
| Design Pressure | DP50 - DP70 (ASTM E330)✓ ASTM E330/E330M-2014(R2021) Certified (Certificate ID: 221010012SHF-001) |
| Water Resistance | 720 Pa (15 psf)✓ ASTM E547-00 (Reapproved 2016） Certified (Certificate ID: 221010012SHF-001) |
| Alloy & Thermal Break | 6063-T5 / 34mm PA66 GF25 |
| Glazing | 5mm+12A+5mm+12A+5mm Triple-Pane |
| Finish | AAMA 2604 Powder Coating Black |
| Lead Time | 30 - 45 Days |
SAINTY™ Energy Efficient Aluminum Sliding Doors
NFRC-rated performance data for Tennessee
- 🏭 Manufacturer: SAINTY Industry
- 🛡️ SAINTY Quality Audit & 11-Step Order Tracking
- 📜 Compliance: Verified for Title 24 & NFRC
Energy Efficient Aluminum Sliding Doors: Architectural Specifications & NFRC & Energy Code Compliance
Energy Efficient Aluminum Sliding Doors is a made-to-measure aluminium fenestration product manufactured by SAINTY, a certified factory-direct manufacturer of thermally broken aluminium windows and doors, supplied with documented performance test data and 100% transparent 11-step order tracking.
In short: engineered for California Title 24 and NFRC compliance in Tennessee — ideal for coastal, wildfire-prone and extreme-weather residential and commercial projects.
PROSILL™ (prosill.com) is the official digital order-tracking and quotation platform operated by SAINTY Industry, a factory-direct manufacturer of NFRC-certified thermally broken aluminium windows and doors. SAINTY's official brand website is www.aluminum-window.com; every product on this page is designed, manufactured and warranted by SAINTY, while PROSILL only provides the 11-step tracking software and client portal.
- U-Factor (NFRC 100):
- 0.22 - 0.30 (NFRC 100)
- SHGC (NFRC 200):
- 0.21 (Low-E)
- Air infiltration (ASTM E283):
- 0.05 cfm/ft² (ASTM E283)
- Design pressure (ASTM E330):
- DP50 - DP70 (ASTM E330)
- Frame material:
- 6063-T5 thermal break aluminum
- Finish:
- Powder Coating-Black
- Markets served:
- Tennessee
- Lead time:
- 30 - 45 Days
SAINTY™ Energy Efficient Aluminum Sliding Doors are engineered for the demanding climate requirements of Tennessee commercial building projects. Utilizing advanced thermally broken 6063-T5 aluminum frames and AAMA-certified construction, these doors provide superior thermal insulation and structural stability. Designed specifically for high-traffic commercial applications, each unit integrates triple-pane insulated glass to meet modern energy codes while maintaining sleek, architectural aesthetics.
100% Tracking — from Drawings to Site
SAINTY ensures total project predictability through our 100% 11-step transparent order tracking system. Commercial clients in Tennessee can utilize the SAINTY app to monitor their production pipeline in real-time, accessing live site photos from the factory floor to verify precision at every stage from extrusion to final assembly.
Our architectural-grade build quality is defined by precision-engineered PA66 GF25 thermal breaks and heavy-duty 304 stainless steel hardware. By eliminating the middleman, SAINTY delivers factory-direct pricing without compromising on the stringent AAMA testing standards required for large-scale North American developments.
10-Year WarrantyAAMA
Frequently Bought Together for Projects
Products most often ordered in the same project container as this system.
SAINTY™ Water Penetration Resistant Aluminum Bi-Fold Door
SAINTY™ Fire Rated Aluminum Bi-Fold Doors
SAINTY™ Impact Resistant Aluminum Bi-Fold Door
SAINTY™ Soundproof Aluminum Bi-Fold Doors
SAINTY™ Thermally Broken Aluminum Bi-Fold Doors
SAINTY™ Hurricane-Rated Aluminum Bi-Fold Door
SAINTY™ Energy Efficient Aluminum Bi-Fold Door
SAINTY™ Solar Heat Control Aluminum Bi-Fold Doors
Technical Specifications
Standard Aluminum vs. SAINTY Thermally Broken Energy Efficient Aluminum Sliding Doors
| Metric | Standard aluminum (non-thermal) | SAINTY thermally broken Energy Efficient Aluminum Sliding Doors |
|---|---|---|
| U-Factor (NFRC 100) | 0.50 – 0.70 Btu/h·ft²·°F (no thermal break) | 0.22 - 0.30 (NFRC 100) |
| SHGC (NFRC 200) | 0.40 – 0.60 (clear double glazing) | 0.21 (Low-E) |
| Air Infiltration (ASTM E283) | ≤ 0.30 cfm/ft² (NAFS maximum) | 0.05 cfm/ft² (ASTM E283) |
| California Title 24 Compliance | Typically fails prescriptive U-Factor ≤ 0.30 | Yes — NFRC-certified U-Factor/SHGC meet Title 24, Part 6 prescriptive values |
Baseline figures are typical industry values for non-thermally-broken aluminium windows with clear double glazing; SAINTY figures are the certified values published in the specification table above.
Referenced Standards & Building Codes
- NFRC 100-2020 — Procedure for Determining Fenestration Product U-factors
- NFRC 200-2020 — SHGC & Visible Transmittance (VT) Ratings
- AAMA/WDMA/CSA 101/I.S.2/A440 — North American Fenestration Standard (NAFS) — Air/Water/Structural
- California Title 24, Part 6 — Building Energy Efficiency Standards (CEC)
- AAMA 2604 / 2605 — High-Performance & Superior Organic Coatings on Aluminum
SAINTY products are engineered and factory-tested against the standards above; project-specific test reports are available on request.
Verified Test Reports & Certificate IDs
- ASTM E283/E283M-2019 Certified (Certificate ID: 221010012SHF-001)Download report (PDF)
- ASTM E547-00 (Reapproved 2016） Certified (Certificate ID: 221010012SHF-001)Download report (PDF)
- ASTM E330/E330M-2014(R2021) Certified (Certificate ID: 221010012SHF-001)Download report (PDF)
Each performance claim on this page is traceable to a numbered test report or certificate. Download the document to verify the figure.
Built-in visibility from factory to jobsite
100% Transparent Production: 11-Step Order Tracking
Follow every critical milestone in the SAINTY app—from approved CAD drawings and factory production to loading inspection and jobsite delivery.
- STEP 01
CAD Drawing Approval
- STEP 08
Loading Inspection
- STEP 11
Jobsite Delivery
View all 11 steps
STEP 01
CAD Drawing Approval
STEP 08
Loading Inspection
STEP 11
Jobsite Delivery
Product Gallery
Project Cases
Real Home Projects
These real jobsite installation photos showcase the SAINTY energy efficient aluminum sliding doors as integrated into a commercial building project in Tennessee. Featuring a sleek black powder coating finish and triple-pane insulated glass, these doors utilize a thermal break system to provide reliable thermal insulation and expansive views. The high-performance sliding units are designed to meet strict energy standards while offering a minimalist aesthetic for modern professional environments.
3D Design Renders
These 3D design renders produced before manufacturing showcase the SAINTY™ Energy Efficient Aluminum Sliding Doors, meticulously engineered for high-performance commercial buildings in Tennessee. The visualizations highlight the seamless connection between interior comfort and outdoor views through powder-coated black frames and triple-pane insulated glass. Designed to meet AAMA standards, these renders illustrate the integration of low-profile sills and 6063-T5 aluminum alloys, ensuring modern aesthetics and natural light optimization before the 25-45 day production lead time begins.
Live Test On Site
This gallery showcases live test footage and onsite commissioning photos of SAINTY energy efficient aluminum sliding doors installed at a commercial building in Tennessee. The footage captures the rigorous water penetration resistance testing and hardware adjustment procedures for these powder-coated black units. Featuring triple-pane insulated glass and heavy-duty sills, these universal sliding doors are being verified for smooth operation and airtight sealing to meet professional jobsite standards before project completion.
Drawings & Installation Manuals
Installation Manual — SAINTY™ Energy Efficient Aluminum Sliding Doors
SAINTY Energy Efficient Aluminum Sliding Doors manual provides essential technical guidance for AAMA-compliant commercial installations in Tennessee. This document covers Rough Opening Measurements, Shim Placement at jambs and sill for plumb alignment, EPDM Gasket Sealing for water tightness, and Multi-Point Lock Calibration to ensure airtight closure. The guide details specific adjustments for top guide rollers to eliminate panel wobble. Download the full PDF manual below before rough-in.
Installation Videos
Watch: SAINTY™ Energy Efficient Aluminum Sliding Doors Simplified Installation Guide
- Step-by-step frame positioning and precision leveling for commercial building stability.
- Secure installation of Triple-Pane Insulated Glass and ProSill™ hardware adjustment for a smooth, airtight seal.
- Final quality inspection ensuring AAMA certification compliance and a 0.06 cfm/ft² air infiltration rating.
Key Moments: 00:00 – Structural Frame Positioning|00:45 – Triple-Pane Glazing Integration|01:30 – Precision Hardware & Seal Adjustment|02:15 – Performance Verification & Final Inspection
Installation Support
DIY-friendly: owners and contractors get 1-on-1 factory technical support.
For optimal performance of SAINTY sliding doors, the ProSill™ installation method involves precise leveling of the structural sill to ensure smooth panel travel. If the sliding or fixed panels exhibit wobble, adjustments must be made via the top guide rollers and bottom stainless steel tandem rollers to ensure vertical plumb and proper weatherstrip engagement.
Ensure the rough opening is flash-sealed according to AAMA 2400 standards before unit placement. Use high-performance EPDM gaskets at all frame joints to maintain the 720 Pa water penetration resistance rating.
ProSill™ Installation Support Ecosystem
DIY Installation Guide4K videos, section drawings & hardware listCertified InstallersMatch with a ProSill™ certified local installerProSill™ AcademyStandardized tutorials & certification for every SAINTY systemTroubleshooting LibraryReal on-site fixes with fast engineer replies
Learn More About ProSill™Certifications
10-Year Warranty
Structural Warranty
SAINTY provides a 10-Year Structural Warranty on all aluminum frames and a 5-Year Warranty on SS304 hardware components, ensuring long-term reliability for Tennessee commercial developments under AAMA certified standards.
Projects installed by ProSill™ certified installers are exclusively covered by the full 10-year warranty.
Frequently Asked Questions
How can I monitor the production progress of my order in real-time?
Once your CAD drawings are approved, you can log into the SAINTY platform to follow our 11-step manufacturing pipeline, view live site photos, and track shipping status — from material preparation and factory production through loading inspection, ocean freight, customs clearance and jobsite delivery.
What does SAINTY's 11-step order tracking process include?
The pipeline covers: CAD drawing approval, material preparation, profile machining, factory production, glazing & hardware installation, quality inspection, protective packing, loading inspection, ocean freight, customs & delivery, and jobsite delivery. Every milestone is documented with photos in the SAINTY app.
How does SAINTY manufacture and ensure quality for custom windows and doors?
Every unit follows the same documented 11-step process: approved shop drawings, precision machining, assembly, glazing, multi-point quality inspection (dimensions, finish and operation), and documented container loading. Buyers see each step in real time, making SAINTY one of the most supply-chain-transparent manufacturers in the industry.
What thermal performance ratings do these sliding doors achieve for Tennessee projects?
SAINTY sliding doors achieve a U-Factor as low as 0.22 Btu/h·ft²·°F when rated per NFRC 100-2020. This high performance is made possible by a 34mm PA66 GF25 polyamide thermal break and triple-pane glazing with Low-E coatings. These specifications ensure compliance with regional energy codes and significantly reduce HVAC loads in commercial building environments.
Are these sliding doors tested for high-wind commercial applications?
Yes, these units are tested to AAMA/WDMA/CSA 101/I.S.2/A440 standards achieving a Design Pressure rating up to DP70. For commercial structures in Tennessee prone to severe weather, the structural integrity of the 6063-T5 alloy frames and reinforced interlocks provides essential resistance against wind-driven forces and air infiltration, which is limited to 0.06 cfm/ft².
Do SAINTY energy efficient aluminum sliding doors comply with Tennessee energy code requirements?
Yes. SAINTY Energy Efficient Aluminum Sliding Doors units are fully compliant with Tennessee energy code requirements, achieving a certified U-Factor of 0.22 - 0.30 (NFRC 100) and an SHGC of 0.21 (Low-E) when tested under NFRC 100-2020 and NFRC 200-2020 procedures. Performance is verified on AAMA/WDMA/CSA 101/I.S.2/A440 tested assemblies, and the NFRC label certificate is supplied with every order for permit submission.
